Hot-Wedge Welding Machine Miniwelder Geo2
Hot-Wedge Welding Machine: Miniwelder Geo2
Model
Miniwelder Geo2
Features
- Lightweight (<4 kg)
- Welding speed up to 7.5m per minute
- Intuitive operation
- Revolutionary chainless drive technology
- Automatic wedge positioning
Technical Specification
|
Voltage V~ |
120/230 |
|
Frequency Hz |
50/60 |
|
Max.power W |
800 |
|
Temperature ℃ |
60-480 |
|
Hotwedge material |
Copper/Chromesteel |
|
Weld seam width mm |
2×12 |
|
Max.overlap mm |
100 |
|
Speed m/min |
0.4-7.5 |
|
Dimensions (L×W×H) mm |
228×228×170 |
|
Weight kg |
3.9 |
|
Conformity marking |
CE |
|
Protection class |
Ⅰ |
|
Weldable materials |
LDPE,PVC*(0.5-1.5 mm) TPO/FPO(0.7-1.5mm) HDPE(0.4-1.0 mm) *PVC only with steel wedge |
Equipment Supply
Instruction manual,transport box,hex wrench,cleaning brush
