Fully Automatic Video Melting Point Instrument With Audit Tracking
The FX-RD-V70 fully automatic melting point instrument perfectly combines high-precision temperature control technology and high-definition video camera technology, not only providing users with accurate, stable, and reliable test results, but also bringing efficient and convenient testing experience to users. High definition videos can easily and clearly see the entire process of sample melting, automatically detect real-time graph display, and facilitate users to accurately measure the sample melting point and melting distance.
Technical Specifications
|
Model |
FX-RD-V30 |
FX-RD-V50 |
FX-RD-V70 |
|
Temperature Range |
room temperature -350 ℃ |
RT-400℃ |
room temperature -350 ℃ |
|
Detection Method |
semi-automatic/manual |
Manual |
fully automatic (compatible with manual) |
|
Processing Capacity |
four samples at the same time) |
four samples at the same time) |
four samples at the same time) |
|
Judgment Ability |
Video visual inspection |
Video visual inspection |
Video visual inspection |
|
Temperature Resolution |
0.1 ℃ |
0.1 ℃ |
0.1 ℃ |
|
Heating Rate |
0.1 ℃ -20 ℃ (200 level infinitely adjustable) |
0.1 ℃ -20 ℃ (200 level infinitely adjustable) |
0.1 ℃ -20 ℃ (200 level infinitely adjustable) |
|
Temperature Control Method |
PID precise temperature control furnace body fully enclosed design |
PID precise temperature control furnace body fully enclosed design |
PID precise temperature control furnace body fully enclosed design |
|
Heating Method |
Conductive liquid heating method or electric block air heating method (optional) |
Conductive liquid heating method or electric block air heating method (optional) |
Conductive liquid heating method or electric block air heating method (optional) |
|
Heating Resolution |
0.1℃ |
0.1℃ |
0.1℃ |
|
Accuracy |
Accuracy: ± 0.3 ℃ (±200 ℃) |
±0.2℃（±200℃）;±0.4℃（＞200℃） |
±0.2℃（±200℃）;±0.4℃（＞200℃） |
|
Repeatability |
Repeatability of melting point at 0.1 ℃/Min ± 0.1 ℃ |
Repeatability of melting point at 0.1 ℃/Min ± 0.1 ℃ |
Repeatability of melting point at 0.1 ℃/Min ± 0.1 ℃ |
|
Correction Function |
√ |
√ |
√ |
|
Exploration Mode |
√ |
√ |
√ |
|
Video Function |
Take photos and videos |
Take photos and videos |
Take photos and videos |
|
Video Playback |
With/With Time Watermark |
With/With Time Watermark |
With/With Time Watermark |
|
HD Camera |
Observe the melting state of the sample |
Observe the melting state of the sample |
Observe the melting state of the sample |
|
Magnification Factor |
≥ 10 |
≥10 |
≥ 20 |
|
Number Of Users Managed |
30 or more, classified into three levels of management |
30 or more, classified into three levels of management |
300 or more, classified into three levels of management |
|
Storage Space |
32G hard disk, ≥ 2GB memory |
32G hard disk, ≥ 2GB memory |
32G hard disk, ≥ 2GB memory |
|
Test Method |
√ |
√ |
√ |
|
Data Storage |
√ |
√ |
√ |
|
Manual Save |
200 |
200 |
300 |
|
Video Saving |
√ |
√ |
√ |
|
Continuous Video Shooting Time |
50mins |
50mins |
50mins |
|
Memory expansion |
√ |
√ |
√ |
|
Experimental Plan |
50sets |
50set |
100set |
|
Audit Trail |
√ |
√ |
√ |
|
Network |
Wireless WIFI |
Wireless WIFI |
Wireless WIFI |
|
Display Method |
8-inch high-definition color screen |
8-inch high-definition color screen |
8-inch high-definition color screen |
|
Data Interface |
USB, network WiFi interface, RS232 |
USB, network WiFi interface, RS232 |
USB, network WiFi interface, RS232 |
|
Data Authenticity |
Tamper proof function |
Tamper proof function |
Tamper proof function |
|
Data Export |
Usable USB drive export |
Usable USB drive export |
Usable USB drive export |
|
Data Output Format |
PDF format and EXCL data |
PDF format and EXCL data |
PDF format and EXCL data |
|
Data overflow reminder |
automatic reminder in advance |
automatic reminder in advance |
automatic reminder in advance |
|
Printer |
Optional laser printer or thermal/needle type (compatible) |
Optional laser printer or thermal/needle type (compatible) |
optional |
|
Capillary Size |
outer diameter φ 1.4mm, inner diameter: φ 1.0mm |
outer diameter φ 1.4mm, inner diameter: φ 1.0mm |
outer diameter φ 1.4mm, inner diameter: φ 1.0mm |
|
Work Power |
220VAC 50HZ Power supply: 120W |
220VAC 50HZ 120W |
220VAC 50HZ Power supply: 120W |
|
Model |
FX-RD-V80 |
FX-RD-V90 |
|
Temperature Range |
room temperature -400 ℃ |
RT-420℃ |
|
Detection Method |
Full automatic (manual compatible ) |
Full automatic (manual compatible ) |
|
Processing Capacity |
four samples at the same time) |
four samples at the same time) |
|
Judgment Ability |
Video visual inspection |
Video visual inspection |
|
Temperature Resolution |
0.01 ℃ |
0.01 ℃ |
|
Heating Rate |
0.1 ℃ -20 ℃ (200 level infinitely adjustable) |
0.1 ℃ -20 ℃ (200 level infinitely adjustable) |
|
Temperature Control Method |
PID precise temperature control furnace body fully enclosed design |
PID precise temperature control furnace body fully enclosed design |
|
Heating Method |
Conductive liquid heating method or electric block air heating method (optional) |
Conductive liquid heating method or electric block air heating method (optional) |
|
Heating Resolution |
0.1℃ |
0.1℃ |
|
Accuracy |
Accuracy: ± 0.2 ℃ (＜200 ℃) |
±0.2℃（＜200℃）;±0.4℃（＞200℃） |
|
Repeatability |
Repeatability of melting point at 0.1 ℃/Min ± 0.1 ℃ |
Repeatability of melting point at 0.1 ℃/Min ± 0.1 ℃ |
|
Correction Function |
√ |
√ |
|
Exploration Mode |
√ |
√ |
|
Video Function |
Take photos and videos |
Take photos and videos |
|
Video Playback |
With/With Time Watermark |
With/With Time Watermark |
|
HD Camera |
Observe the melting state of the sample |
Observe the melting state of the sample |
|
Magnification Factor |
≥ 10 |
≥10 |
|
Number Of Users Managed |
＞500, classified into three levels of management |
＞500, classified into three levels of management |
|
Storage Space |
64G hard disk, ≥ 2GB memory |
128G hard disk, ≥ 2GB memory |
|
Test Method |
√ |
√ |
|
Data Storage |
√ |
√ |
|
Manual Save |
300 |
800 |
|
Video Saving |
√ |
√ |
|
Continuous Video shooting Time |
50mins |
50mins |
|
Memory Expansion |
√ |
√ |
|
Experimental Plan |
300 |
600 |
|
Audit Trail |
√ |
√ |
|
Network |
Wireless WIFI |
Wireless WIFI |
|
Display Method |
8-inch high-definition color screen |
8-inch high-definition color screen |
|
Data Interface |
USB, network WiFi interface, RS232 |
USB, network WiFi interface, RS232 |
|
Data Authenticity |
Tamper proof function |
Tamper proof function |
|
Data Export |
Usable USB drive export |
Usable USB drive export |
|
Data Output Format |
PDF format and EXCL data |
PDF format and EXCL data |
|
Data Overflow Reminder |
automatic reminder in advance |
automatic reminder in advance |
|
Printer |
Optional laser printer or thermal/needle type (compatible) |
Optional laser printer or thermal/needle type (compatible) |
|
Capillary Size |
outer diameter φ 1.4mm, inner diameter: φ 1.0mm |
outer diameter φ 1.4mm, inner diameter: φ 1.0mm |
|
Work Power |
220VAC 50HZ Power supply: 120W |
220VAC 50HZ 120W |
Features
1. Automated integration, achieving one click measurement function;
2. Process 4 samples at once;
3. High definition videos replace traditional microscopes for high visual acuity;
4. Fully automatic recording of melting process, initial melting, final melting;
5. Data can be directly printed through a printer;
6. Complies with 21CFR Part 11, audit trail, pharmacopoeia, and electronic signature.
7. Comply with GLP requirements and specifications
Applications
The melting point instrument holds an important position in the chemical industry and pharmaceutical research, and is an essential instrument for the production of food, drugs, spices, dyes, and other organic crystal substances.
