Features
² Color High contrast LCD touchscreen, 4.3 inches.
² Intelligent operation system provides features including user management, calibration management, electrode management, method management, data management, Log Management and etc.
² Multi-reading feature allows auto-read, timed-read and continuous-read.
² Automatic/Manual temperature compensation ensures accurate results.
² Auto-hold feature senses and locks the measurement endpoint.
² Data Storage 1000 sets for each parameter (GLP-compliant).
² Data analysis feature helps user review, compare and recalculate results.
² Support for USB communication.
² Auto-power off feature effectively extends the battery service life.
² Reset feature automatically resumes all settings back to factory default options.
² IP65 waterproof. The portable meter is suitable for fields measurements and out door measurements.
² 1-8 points calibration with Standard Recognition.
² Selectable pH buffer groups, including USA, NIST, DIN, GB, MERK, JIS.
² User-defined pH buffer or buffer group is supported.
² Automatic electrode diagnosis with pH slope and offset display.
² E-301-QC 3 in 1 pH composite electrode
² NIST pH standard solution(4.01, 7.00, 10.01) , 50ml/vial
² Electrode holder
² Silicone rubber case
² Wristbands
² Touch pen
² Carrying case
Parameters
Parameters |
pH/Temp.(mV/ORP) |
|
pH
|
Range |
-2.000 to 20.000 pH |
Resolution |
0.1, 0.01, 0.001pH |
|
Accuracy |
±0.002 pH |
|
Slope Limit |
Yes |
|
mV/ORP
|
Range |
-2000.00 to 2000.00 mV |
Resolution |
0.1, 0.01 mV |
|
Accuracy |
±0.1 mV or ±0.03% |
|
EH ORP Mode |
Yes |
|
ORP Calibration Points |
1 custom point (relative mV) |
|
Temperature
|
Range |
-10 to 135 ºC, 14 to 275 ºF |
Unit |
ºC, ºF |
|
Resolution |
0.1 |
|
Accuracy |
±0.1ºC |
|
Measurement
|
Reading Mode |
Auto Read (Fast, Medium, Slow), Timed, Continuous |
Reading Prompts |
Reading, Stable, Locked |
|
Temp. Compensation |
ATC, MTC |
|
General
|
Power |
Rechargeable Lithium battery, AC Adapter, 100-240V AC input, DC5V output |
Dimensions |
90×255×40 mm |
|
Weight |
500g (1.1 lb) |
|
Dimensions (Carton) |
410×330×165 mm |
|
Weight (Gross) |
5.5 kg |
