PFP210 Full Automatic Open Cup Flash Point Tester
This tester is used to determine the petroleum and asphalt flash point & light point by Cleveland open cup method, except the fuel oil and those whose open flash point is lower than 79°C. Max features: Accurate temperature rise rate. Highly automated. It's kind of an advanced asphalt testing instrument in laboratory.
Technical Specifications
| Standards | GB/T 3536 ISO 2592 ASTM D92 | Storage Temperature | -20～50℃ |
| Testing Range | 79～400℃ | Safe Temperature | EFP+20℃ |
| Power Supply | AC220V，50Hz | Pre-Safe Temperature | EFP+10℃ |
| Total power | 1500W | Absolute Safe Temperature | 400℃ |
| Heating power | 1300W | Ignition Mode | Electric or gas ignition |
| Working Temperature | 0℃～40℃ | Display Resolution | 640×480 |
| Display | Color LCD,6.4" | Weight | 32Kg |
| Overall Dimension | 478×376×322 mm (L×W×H) | ||
Packing List
|
No. |
Item |
Qty |
Remark |
|
1 |
Sample cup |
1pc |
Copper with gold plating |
|
2 |
Fuse wire |
1pc |
|
|
3 |
Electric igniter |
1pc |
|
|
4 |
Mouse |
1pc |
|
|
5 |
Keyboard |
1pc |
|
|
6 |
Fuse tube |
2pcs |
|
|
7 |
Power cable |
1pc |
|
|
8 |
Touch pen |
1pc |
|
|
9 |
User manual |
1pc |
|
|
10 |
Certificate |
1pc |
|
Main Features
1) Dual control system: The open cup flash point tester adopts a hardware system consisting of an industrial computer and a microcontroller. The microcontroller is used to control the heating process and collect sensor data, resulting in high real-time testing and more accurate testing results; The use of an industrial computer as the overall system control makes the instrument more reliable. The industrial computer has 256M of memory and 2GB of hard disk, which not only runs at a speed block but also has a large amount of data storage. Adopting the Windows CE 5.0 operating system not only facilitates user operation (similar to the Windows XP system on a PC), but also avoids the risk of disease invasion as Windows CE belongs to an embedded independent file system. The software adopts a fully Chinese operating interface (which can be replaced with an English interface), making it easy to understand.
2) Multiple interfaces: For the convenience of users, multiple communication interfaces such as RS-232, USB, and RJ-45 are provided, which can connect to the LIMS system, connect to the local area network, and browse the Internet; Through the USB interface, not only can the system software be directly upgraded, but also experimental result data can be exported; At the same time, the instrument provides an LPT printing interface, which can directly connect to a laser printer to print test results reports.
3) True color display: Equipped with a 24 bit true color TFT LCD screen and touch screen, it is more convenient for users to operate, and is also equipped with a mouse and keyboard.
Main Features
4) Dual ignition system: Electronic ignition is used to ignite gas, without the need for manual ignition by the user. Moreover, the instrument will automatically detect whether the flame is extinguished. If the flame is blown out, the instrument will automatically ignite and sweep the flame.
5) Self inspection and self diagnosis: When the open cup flash point tester is turned on, it automatically performs self inspection on the flash point sensor, Pt100 oil temperature sensor, electronic igniter, system hot fuse, etc; Simultaneously perform self checks on the electronic igniter, ignition sweep action, cooling and heating system startup/reset, etc. If there is a malfunction or abnormal connection, the instrument will emit a beep alarm and display a text prompt on the screen“ ××× Abnormal, please check if it is connected.
6) Automatic fire extinguishing: The instrument can not only detect flash point but also ignition point. After the test is completed, the instrument will automatically pop out the fire extinguishing cover to extinguish the fire.
7) Split independent design: Both the flash point sensor and temperature sensor adopt a split independent design, which makes it easier to replace various accessories (user plug and play).
8) Imported components: The temperature sensor is imported from Germany, making the detection more reliable and stable, and the data more accurate.
Main Features
9) Overheat protection: The open cup flash point tester has an overheating protection function. If the pre safety temperature (safety alarm temperature) is exceeded, an audible and visual alarm will sound but the test can continue; When the safe temperature (test stop temperature) or safe temperature (400 ℃) is exceeded, an audible and visual alarm will be issued to stop the test, and the cooling fan will be started to forcibly cool down to prevent accidents such as fires.
10) Intuitive test results: the instrument has the function of atmospheric pressure correction; Has powerful data storage and query functions; The instrument can store tens of thousands of test results and can be freely combined and queried by time, oil sample, tester, etc.
11) Multiple test procedures: has six standard test procedures to choose from, and users can set their own experimental standards based on their own experimental methods and data requirements (to meet the requirements of rapid testing of unknown oil samples).
