Environmentally friendly digital vibrating screen machine
Product Introduction
The structure of this machine is mainly composed of a frame, an upper cover, a slewing structure, a shock mechanism, a clamping mechanism and a set of screens. It has a variety of advantages, such as small size, light weight, and beautiful appearance. Equipped with automatic stop device, advanced structure, good performance, large rotation amplitude, strong shock force, good screening effect, environmental protection, convenient and flexible use of jacket screen.
Technical parameters
1. Model: ZY-SF-200S
2.Control mode: Intelligent digital display control
3.Standard sieve diameter : 200mm
4.Number of sieve shakes : 221 times/min
5.Number of vibrations : 147 vibrations/min
6. Swing radius :12.5mm
7. Motor power : 0.37kw
8.Number of motor revolutions :1400r/min
9.Screen stack height: 400mm
10.Amplitude travel of the upper and lower amplitude : 5-8mm
11. Timer range: 0-60 minutes
12. Voltage: 380V
13. Dimensions: 650×430×1050mm
14.Weight: 160KG
Application
The environmentally friendly standard vibrating screen machine is suitable for geology, electric power, metallurgy, chemical industry, coal, national defense, scientific research, grinding wheel, cement, building materials and other departments. It is used for sieving and analysis of materials in laboratory and laboratory. It conforms to the standard GB474-2008 "Preparation Method of Coal Sample".
