Handheld Ultrasonic Cell crusher Portable Ultrasonic Processor Ultrasonic Disrupter Disintegrator
Features
●Full-featured, beautiful appearance, reliable performance, using single-chip technology + 4.3-inch TFT capacitive touch screen control (optional 7-inch), optional computer communication or data printing and other functions;
●High degree of intelligence, centralized control by central microcomputer, ultrasonic time, power can be set from 1%-100%
●Sample temperature detection and display, frequency microcomputer automatic tracking, automatic fault alarm;
Equipped with a set of Alcoa 7075 transducer + high-purity titanium alloy horn, the industrial horn can continuously achieve ultrasound for more than one hour (only high-purity titanium alloy can be achieved);
●With overload protection function and the horn is not immersed in the liquid, it will automatically protect the horn from damage;
●It can realize the voice alarm function caused by fault, over temperature or operation error, which is more humanized;
Specifications
|
Model |
ZY-CS-FS-250W |
ZY-CS-FS-400W |
|
Power |
2.5-250W continuously adjustable |
4-400W continuously adjustable |
|
Crushing capacity |
0.1-150ML (need to select the corresponding horn) |
0.1-300ML (need to select the corresponding horn) |
|
Display method |
True color capacitive touch screen display |
True color capacitive touch screen display |
|
Single ultrasound time |
0.1-99.9S |
0.1-99.9S |
|
Single gap time |
0.1-99.9S |
0.1-99.9S |
|
Total time (ultrasound + gap) |
1-99H59M59S |
1-99H59M59S |
|
Frequency range |
20-30KHz |
20-30KHz |
|
Temperature control range |
0-100 degrees (optional low temperature constant temperature) |
0-100 degrees (optional low temperature constant temperature) |
|
Alarm function |
time, overload, no-load, over temperature |
time, overload, no-load, over temperature |
|
Random horn |
Φ5(mm) |
Φ5(mm) |
|
Optional horn |
Φ2, 3, 5, 6(mm) |
Φ2, 3, 5, 6(mm) |
|
Data storage |
20 groups |
20 groups |
|
Power supply (optional 110V) |
220V/110V/50Hz/60HZ |
220V/110V/50Hz/60HZ |
|
Instrument size |
410*225*290mm |
410*225*290mm |
|
Way to control |
MCU + TFT touch |
MCU + TFT touch |
|
Optional features |
Computer communication + data printing |
Computer communication + data printing |
|
Voice alarm and prompt function |
have |
have |
