ZR-17662 Fire Resistance Tester of Insulated Gloves
Model
ZR-17662
Standards
Other testing standards: AQ 6103
EN European Standard: EN 60903:2003
GB China National Standard: GB/T 17622:2008
Features
1. Standard stainless steel box, equipped with transparent observation windows, can detect the flame spread rate in a timely manner;
2. Equipped with one stopwatch timer and one ignition device each;
3. Needle valve adjusts the height of the flame;
4. The burner is fixed on a sliding track for easy operation, and the needle valve can adjust the flame height;
5. Equipped with a Bunsen lamp that meets the ASTM D5025 standard, with an inner diameter of 9.5mm ± 0.3mm and adjustable flame temperature and height;
6. Equipped with two GB/T17622-2008 6.6.2 standard stainless steel specimen holders;
7. Equipped with a flame height gauge.
Specifications
|
Dimensions |
500mm (W) X 550mm (H) X 300mm (D) |
|
Weight |
19KG |
|
Power Requirements |
220V, 50Hz, 3A |
|
Environmental Requirements |
temperature (20 ± 2) ° C, humidity (65 ± 5)% |
|
Gas Requirements |
Propane |
